Engine: BF20

Type: 4-Stroke SOHC 2 Cylinder/4 Valves

Displacement: 350 cc (21.5 cubic inches)

Bore & Stroke: 59 mm x 64 mm (2.3 x 2.5 inches)

Full Throttle RPM Range: 5,000-6,000 RPM

Rated Power: 20 HP @ 5,500 RPM

Cooling System: Water Cooled

Fuel Delivery: 1 Carburetor

Ignition System: PGM-IG

Starting System: Electric/Recoil

Exhaust: Through Hub

Lubrication: Wet Sump

Trim Range: 4 Stage 8°-12°-16°-20°

Tilt Range: 72°

Drive

Gear Ratio: 2.08:1

Gear Shift: F-N-R

Equipment

Alternator with voltage regulator (Electric Start): 12-Amp (151 watt)

Alternator with voltage regulator (Manual Start): 6-Amp (76 watt)

Propeller: 4-Blade Aluminum

Diameter x Pitch, Standard: 9¼ x 10 inches

Diameter x Pitch, Power Thrust: 10 x 7? inches

Power Tilt: Available

Oil Pressure Alert: Standard

Temperature Alert: Standard

Rev-Limiter: Standard

Dimensions

Overall Width: 350 mm/13.8 inches

Transom Height

S Type: 381 mm/15 inches

L Type: 508 mm/20 inches

X Type: NA

Dry Weight

S-Type: 47 kg/104 lbs.

L-Type: 50 kg/110 lbs.

X-Type: NA
