Engine: BF8

Type: 4-Stroke SOHC 2 Cylinder/4 Valves

Displacement: 222 cc (13.5 cubic inches)

Bore & Stroke: 58 mm x 42 mm (2.3 x 17 inches)

Full Throttle RPM Range: 4,500-5,500 RPM

Rated Power: 8 HP @ 5,000 RPM

Cooling System: Water Cooled

Fuel Delivery: 1 Carburetor

Ignition System: PGM-IG

Starting System: Electric/Recoil

Exhaust: Through Hub

Lubrication: Wet Sump

Trim Range: 5 Stage 4°-8°-12°-16°-20°

Tilt Range: 71°

Drive

Gear Ratio: 2.33:1

Gear Shift: F-N-R

Equipment

Alternator with voltage regulator (Electric Start): 12-Amp (148 watt)

Alternator with voltage regulator (Manual Start): 6-Amp (76 watt)

Propeller: 4-Blade Aluminum

Diameter x Pitch, Standard: 9¼ x 8 inches

Diameter x Pitch, Power Thrust: 10 x 6.5 inches

Power Tilt: Available

Power Trim & Tilt: NA

Gas Assisted Tilt: NA

Oil Pressure Alert: Standard

Temperature Alert: Standard

Rev-Limiter: Standard

Dimensions

Overall Width: 345 mm/13.6 inches

Transom Height

S Type: 381 mm/15 inches

L Type: 508 mm/20 inches

X Type: 635 mm/25 inches

Dry Weight

S-Type: 42 kg/92 lbs.

L-Type: 44 kg/98 lbs.

X-Type: 48 kg/107 lbs.
